The prefect design of the bucket is helpful efficient digging, filling and bucket breakout force, making our buckets are widely welcomed by contractors while guaranteeing quality and longevity.Manufactured to any width and bucket capacity as required by customer.High quality materials, ex Q345B, NM360/400, HARDOX450/500.OEM Standard Buckets.Strong and durable construction to withstand robust working conditions.
| Model | PA12 | PA20 | PA25 | PA30 | PA35 |
| Bucket width(mm) | 1626(64") | 1778(70") | 1830(72") | 2032(80") | 2135(84") |
| Self weight(kg) | 980 | 1430 | 1570 | 1750 | 1890 |
| Cylinder number(pcs) | 2 | 2 | 2 | 2 | 2 |
| Max tilt degree(°) | ±45 | ±45 | ±45 | ±45 | ±45 |
| Bucket capacity(cum) | 0.62 | 1.02 | 1.27 | 1.5 | 1.98 |
| Excavator (ton) | 11-16 | 17-21 | 22-29 | 30-36 | 37-45 |
| TYPE | MATERIAL | G.E.T | APPLICATION |
| GD Bucket | Q345B | Adapter,Teeth,Side cutter | Mainly used for excavation and sand, gravel and soil and other light load operating environment. |
| HD Bucket | Q345B | Adapter,Teeth,Side cutter | Mainly used for digging hard soil, mixed with a relative soft stone and clay, softer stones and other light load operating environment. |
| SD Bucket | Q345 & NM400 | Adapter,Teeth,Side cutter/protector | Mainly used for mining hard gravel mixed with hard soil, sub-hard stone or flint, after blasting or loading, and heavy-loading. |
| XD Bucket | Q345 & NM400/HARDOX450/HARDOX500 | Adapter,Teeth,Side protector,Corner shrouds | Mainly used for very high abrasion conditions including high quartzite granite,broken slag,sandstone and ore. |
| Mini Bucket | Q345B | Adapter,Teeth,Side cutter | Used for light work environments with small excavators. |
| Trench Bucket | Q345B | Adapter,Teeth,Side cutter | Used for rivers, ponds and ditches environment. |
| Cleaning Bucket | Q345B & NM400 | \ | Applied to cleaning work in channels and ditches. |
| Skeleton Bucket | Q345B & NM400 | Adapter,Teeth,Side cutter/protector | Applied in integrating sieving and excavation of relatively loose materials. |
Product features:
1）Reinforced Cutting Edge:
The cutting edge is reinforced for enhanced durability and improved penetration, making it well-suited for breaking and handling hard rock.
2）Optimized Bucket Shape:
The bucket's design is optimized to maximize material retention and facilitate efficient loading, ensuring effective rock handling with each scoop.
3）Wear-Resistant Design:
Incorporating wear-resistant components, the rock bucket minimizes wear and tear during continuous rock-handling operations, contributing to extended service life.
4）Quick Attachment and Operation:
Designed for quick and secure attachment to excavators, the rock bucket allows for efficient task-switching and streamlined workflow.
5）Compatibility with Excavator Models:
Engineered to be compatible with a range of excavator models, the rock bucket offers adaptability and ease of integration into existing equipment fleets.
6）Enhanced Tooth System:
Equipped with an enhanced tooth system, the bucket ensures effective penetration and breaking of rocks, optimizing overall rock-handling efficiency.
7. Are you a manufacturer?
* Yes,our factory was established in 2000 year in Yantai, Shandong. and we have ability to trading.
